DipTrace - Professional PCB-Design Tool

Are you looking for a professional and easy-to-use PCB Design software with powerful autorouter and reasonable price?

Try DipTrace and you will be surprised! DipTrace is a complete state-of-the-art PCB Design System. It includes:

  • PCB Layout - PCB design with an easy to use manual routing tools and autorouter.

  • Schematic - Schematic Capture and export to PCB.

  • Pattern Editor - allows you to create part footprints.

  • Component Editor - allows you to draw parts and make components.

Schematic Capture PCB Layout

Watch DipTrace in action!

DipTrace provides the following features:

Easy to learn user interface

To design a schematic, simply select and place components onto your document and connect them together using the wire and bus tools. Multisheet design is supported. Then select the menu option 'Switch to Board' to convert the schematic to PCB. Layout can be updated from Schematic in a few clicks at anytime. When you create or edit design objects they are highlighted to improve your work. Step-by-step tutorial available from web-site guides you through the design process and allows to get started with ease.

Easy to use manual and powerful automatic routing

DipTrace PCB software includes an advanced automatic router that is able to route single-layer and multi-layer boards. It is available with a 'rip-up and retry' algorithm. Autorouter achieves high completion rates by going back and re-routing nets to make space for connections that could not be routed on a previous pass. Intelligent manual routing tools allow you to create and edit traces by 90, 45 degree or without any limitations. Through, blind or buried vias can be used in automatic and manual routing. Unlimited board size is supported.

Shape-based copper pour

Powerful copper pour system can help to reduce your manufacturing costs by minimizing the amount of etching solution required. To use it, all you have to do is insert a copper area on your board in the PCB Layout program and any pad or trace inside the selected area will be automatically surrounded with a gap of the desired size. Using copper pour you can also create planes and connect them to pads and vias (different thermal types are supported).

Advanced Verification Features

Schematic and PCB design modules have number of verification features that help control project accuracy on different design stages: The ERC function shows possible errors in Schematic pin connections using defined rules and allows you to correct errors step-by-step. DRC function checks the clearance between design objects, minimum size of traces, and drills. Errors are displayed graphically and you can fix them step-by-step and rerun the DRC in one click after any corrections. Net Connectivity Check verifies if all nets of PCB are electrically connected. This feature uses traces, copper pour filled area and shapes to control connectivity, then reports broken and merged nets with area details. Comparing to Schematic allows you to check if routed PCB is identical with Schematic.

Import/Export Features

Package modules allow you to exchange schematics, layouts and libraries with other EDA and CAD packages. DipTrace Schematic Capture and PCB Layout also support Accel, Allegro, Mentor, PADS, P-CAD, Protel and Tango netlist formats.

Manufacturing output formats

DipTrace provides support for a number of different manufacturing output formats. Using this PCB software you can produce N/C Drill files for numerically controlled (N.C.) drilling machines and RS-274X Gerber files for sending to board manufacturers. Vectorizing function allows to export true-type fonts and raster images. Also DipTrace supports DXF output.

Producing PCBs using milling method

DipTrace allows you to export edge polylines to DXF. The DXF files can be converted to G-code with Ace Converter (it's free). Before edge exporting the DRC function of pcb layout program checks the design and shows possible problems if exist.

Standard component libraries

DipTrace package includes component and pattern libraries which contain 50.000+ components from different manufacturers.

Creation of your own libraries

Component and Pattern Editors allow to design your own symbols and patterns. To create complete components simply connect them together using Component Editor.

... and much more!

If you are interested in DipTrace, feel free to contact us! Our sales personnel is more than ready to be at your assistance.
